Acrylic Clean Booth / Acrylic Clean Enclosure
The Acrylic Clean Booth is a modular, self-supporting contamination control enclosure designed to create a local clean zone within a general workshop or existing cleanroom. Constructed with transparent acrylic panels and an industrial-grade frame, it provides excellent visibility, easy access, and reliable particle protection for sensitive processes. This unit is ideal for applications requiring ISO Class 6–7 (Class 1,000–10,000) cleanliness without the cost of building a permanent cleanroom.
Request a Free Quote
Acrylic Clean Booth & Acrylic Clean Enclosure: Localised Contamination Control
The acrylic clean booth and acrylic clean enclosure are precision-engineered, self-supporting containment solutions that create an ISO Class 5–7 clean zone inside a general workshop or existing cleanroom — built for laminar airflow, low particle generation, and rapid deployment. For teams that also evaluate laminar flow hood manufacturers, these booths deliver workstation-level cleanliness without the cost of a full-scale room.
As part of our Malaysia prefabricated cleanrooms programme, the acrylic booth integrates with our clean room partition panels, air tight sliding cleanroom doors and FFU ceiling systems — engineered by an established Malaysia cleanroom manufacturer for semiconductor, biopharma, optics and EV-battery production.
Acrylic Clean Booth Specifications
Standard configuration for the Wonclean acrylic clean booth. Footprint, filtration and acrylic thickness are all customizable to project and cleanroom classification requirements.
| Cleanliness class | ISO Class 5–7 (≤ 3,520–352,000 particles/m³ ≥ 0.5 µm) |
|---|---|
| Acrylic panel thickness | 10 mm standard (15 mm optional) |
| Optical clarity | > 92% |
| Surface resistivity | 10⁶–10⁹ Ω/sq (static-dissipative) |
| Frame material | Anodized aluminum 6063-T5 |
| Filtration | HEPA H14 (99.995% @ 0.3 µm) or ULPA U15 (99.9995% @ 0.12 µm) |
| Airflow velocity | 0.3–0.5 m/s |
| Power supply | 220–240 V AC, 50/60 Hz, single-phase (110 V option) |
| Footprint options | W600 × D600 × H1800 to W1500 × D900 × H2200 mm |
| Assembly time | under 4 hours |
| Compliance | ISO 14644-1 · IEST-RP-CC001.4 · CE · RoHS · UL 61010-1 |
Values shown are standard/representative configurations. Confirm final certified figures (filter leak test, airflow validation) against the project datasheet before specification — Wonclean issues a stamped datasheet with every quotation.
Acrylic Clean Booth Construction
Transparent acrylic on a lightweight aluminum frame is the engineering secret. It combines full-visibility monitoring with reliable particle protection, while gasketed seams and HEPA/ULPA laminar flow maintain a stable clean zone — and individual panels swap out without dismantling the enclosure.
Why Choose Our Acrylic Clean Booth
Full visibility
Transparent acrylic panels (> 92% clarity) enable visual process monitoring and easy access.
Rapid deployment
Lightweight self-supporting frame assembles in under 4 hours without structural modification.
Panel-level serviceability
Individual panels are replaceable without disassembling the full enclosure, cutting downtime.
ESD-safe option
Static-dissipative coating (10⁶–10⁹ Ω/sq) protects sensitive electronics assembly.
Flexible configurations
Benchtop or floor-standing layouts with glove-port access and VHP compatibility available.
Smart integration
IoT-enabled controller options with SCADA integration and easy-clean, sanitizer-resistant surfaces.
Acrylic Clean Booth Applications
Deployed as visible, local clean zones across regulated and high-precision industries. See real cleanroom project case studies or browse the full cleanroom product range.
Get a project-specific quote in 24 hours
Send your cleanroom classification, floor area and finish requirements. Our Malaysia-based engineering team replies with a stamped datasheet, fire certificate and pricing — 7×24 technical support by email, phone or WhatsApp.
Request a Free Quote Chat on WhatsAppWhere should air showers be installed in a cleanroom?
Install between changing rooms and clean areas, or between ISO 8/ISO 7 classified areas and unclean areas. Personnel pass through after changing into cleanroom clothing but before entering the controlled environment
What is involved in the construction of a modular cleanroom?
To assemble laboratory spaces efficiently, modular components are preferred. An assembled cleanroom utilizes prefabricated sections to reduce on-site construction time. The underlying aluminum profile system provides the necessary framework for mounting panels and doors, ensuring precision alignment and structural rigidity throughout the facility.
What are the key considerations for air shower design?
Selecting the right air shower requires careful planning. Proper air shower design ensures effective personnel decontamination before entering controlled environments. Specifications depend on room size. Consulting an experienced air shower manufacturer helps determine optimal placement. Compliance with standards is essential. Regular maintenance schedules must be established to sustain performance over time.
What defines quality in clean room door systems?
Sealing integrity is vital. air tight sliding clean room doors prevent pollutants from entering. Each air tight sliding cleanroom door must meet pressure ratings. Reputable air tight sliding cleanroom door manufacturers provide leakage certification. Automatic mechanisms reduce human contact risks. Material selection prioritizes durability and ease of cleaning to meet hygiene protocols. Installation requires precise alignment.
