Clean room double glass window
Clean room double glass window, also called as the insulating glass window, it is a product in which two sheets of glass are fixed with aluminum frames and sealed with a sealant to form a dry gas space between the glass layers or to be filled with an inert gas.
Request a Free Quote
Clean Room Double Glass Window: Insulated Flush Vision Panels
The clean room double glass window (insulating glass window) fixes two glass sheets in aluminium frames sealed to form a dry or inert-gas cavity — delivering thermal insulation, condensation control and a flush, easy-clean glass partition wall cleanroom vision panel with no particle-trapping ledges.
It coordinates with our clean room single glass window and clean room glass door ranges, supplied within our Malaysia prefabricated cleanrooms programme.
Cleanroom Double Glass Window Specifications
Standard configuration for the Wonclean cleanroom double glass window. Glass, cavity and frame are all customizable to project and cleanroom classification requirements.
| Construction | Two tempered low-iron panes (6+6 mm), 16 mm argon cavity, warm-edge SS spacer |
|---|---|
| U-value | ≤ 1.3 W/m²·K (ISO 10292 tested) |
| Frame material | Anodized aluminum 6063-T5, powder-coated RAL 9006 or custom |
| Seal system | Dual-stage silicone gasket + EPDM perimeter compression seal |
| Fire rating | Class B1 (ASTM E84, non-combustible) |
| Particle shedding | ISO Class 1 compliant surface finish (Ra ≤ 0.4 µm) |
| Mounting | Standard interface for 100–300 mm wall thicknesses |
| Condensation | Zero condensation risk at dew-point interfaces |
| Vapor resistance | Solvent-vapor permeation resistant |
| Cleanliness grade | ISO 14644-1 Class 3–8 ready |
Values shown are standard/representative configurations. Confirm final certified figures (U-value, fire test) against the project datasheet before specification — Wonclean issues a stamped datasheet with every quotation.
Cleanroom Double Glass Window Construction
The hermetic argon cavity is the engineering secret. Two tempered low-iron panes on a warm-edge stainless spacer form an insulating unit with U ≤ 1.3 W/m²K — eliminating condensation at dew-point interfaces while a crevice-free perimeter resists microbial entrapment.
Why Choose Our Cleanroom Double Glass Window
Zero condensation
The argon cavity and warm-edge spacer eliminate condensation at dew-point interfaces.
Hermetic seal
A hermetic seal prevents cross-contamination between classified and non-classified zones.
Thermal efficiency
U ≤ 1.3 W/m²K gives consistent thermal performance for temperature-stable cleanrooms.
Crevice-free perimeter
Crevice-free perimeters resist microbial entrapment and ease cleaning.
Vapor-resistant
Solvent-vapor permeation resistance protects sensitive processes near the window.
Wide wall fit
Standard mounting interface fits 100–300 mm wall thicknesses for flexible installation.
Cleanroom Double Glass Window Applications
Specified as insulating cleanroom vision panels across regulated and high-precision industries. See real cleanroom project case studies or browse the full cleanroom product range.
Get a project-specific quote in 24 hours
Send your cleanroom classification, floor area and finish requirements. Our Malaysia-based engineering team replies with a stamped datasheet, fire certificate and pricing — 7×24 technical support by email, phone or WhatsApp.
