Cleanroom Equipment
Single-Person Air Shower Room
Self-contained Air Shower/ Air tunnel systems by Terra remove surface-deposited particles from personnel garments and equipment before entering the clean room.
Request a Free Quote
Single-Person Air Shower Room: Personnel Decontamination Airlock
The single-person air shower room is a self-contained air-shower/air-tunnel system that removes surface-deposited particles from garments and equipment before personnel enter the cleanroom. As an experienced air shower manufacturer, we tune nozzle velocity and cleanroom air flow for effective, gentle particle removal.
For complete personnel and goods flow, pair it with our multi-person air shower room / air shower tunnel and cargo air shower room, supplied within our Malaysia prefabricated cleanrooms programme.
Single-Person Air Shower Room Specifications
Standard configuration for the Wonclean single-person air shower room. Nozzles, cycle time and controls are all customizable to project and cleanroom classification requirements.
| Chamber dimensions | 800×1,200×2,100 mm |
|---|---|
| Nozzle configuration | 24 adjustable stainless nozzles (12 front, 12 rear) |
| Air velocity | ≥ 25 m/s at nozzle exit |
| HEPA filter efficiency | H14 (EN 1822), ≥ 99.995% @ 0.1–0.2 µm |
| Cycle time | 10–30 s (default 15 s) |
| Control system | IP65 touchscreen with cycle logging and filter tracking |
| Power supply | 220–240 V AC, 50/60 Hz, 3.2 kW max |
| Materials | 304 stainless steel interior/exterior, non-shedding epoxy-coated aluminum frame |
| Validation | Pre-calibrated anemometer ports, IQ/OQ documentation templates |
| Cleanliness grade | ISO 14644-1 Class 5 background compatible |
Values shown are standard/representative configurations. Confirm final certified figures (airflow, filter integrity) against the project datasheet before specification — Wonclean issues a stamped datasheet with every quotation.
Single-Person Air Shower Room Construction
Targeted nozzle placement is the engineering secret. 24 adjustable stainless nozzles drive ≥ 25 m/s HEPA-filtered air at high-shedding zones, with real-time airflow validation and interlocked doors — a low-vibration design with filter-life tracking for dependable personnel decontamination.
Why Choose Our Single-Person Air Shower Room
Targeted decontamination
24 adjustable nozzles focus ≥ 25 m/s air on high-shedding garment zones for > 99.9% removal.
Real-time validation
Live airflow validation and pre-calibrated anemometer ports confirm performance each cycle.
Safe interlocking
Interlocked doors and IR occupancy sensors prevent simultaneous opening and bypass.
Programmable control
IP65 touchscreen with cycle logging, filter tracking and alarm history for full traceability.
Low-vibration design
Quiet, low-vibration operation suits cleanrooms adjacent to sensitive metrology areas.
Validation-ready
IQ/OQ documentation templates included for streamlined qualification.
Single-Person Air Shower Room Applications
Specified as personnel air shower entrances across regulated and high-precision industries. See real cleanroom project case studies or browse the full cleanroom product range.
Get a project-specific quote in 24 hours
Send your cleanroom classification, floor area and finish requirements. Our Malaysia-based engineering team replies with a stamped datasheet, fire certificate and pricing — 7×24 technical support by email, phone or WhatsApp.
